WASHER 8.5
Position: 29
0010-023305
WASHER 12
Position: IP
0010-021014
WASHER 10
Position: 42
0800-011005
WASHER 10
Position: 20
0010-060010
THRUST WASHER, CRANKCASE
Position: 28
0800-011003
SWITCH, OIL PRESSURE (OLDER ENGINES) - REPL BY 0800-012400 + 0800-012401
Position: 10
01A0-012200
SLEEVE, GEARSHIFT
Position: 22
0800-011106
SHAFT, BREATHER
Position: 50
0800-011202
SEAT, BREATHER
Position: 46
0800-011105
SCREW PLUG REPL BY 0800-011006-00001
Position: 12
0800-011006
SCREW M4x10
Position: 25
30122-040010850
ROLLER NEEDLE P5x11.8
Position: 24
30406-00500
RESTRICTION PLUG REPL BY 0800-011013-00001
Position: 13
0800-011013
PLUG, SEAL
Position: 06
0130-011400
PLATE, OIL STRAINER
Position: 28
0800-011008-1000
PLAIN BEARING KIT, MAIN SHAFT - SAME AS 0800-0111A0-00001 RED
0800-0111A0
PLAIN BEARING KIT, MAIN SHAFT - REPL BY 0800-0111B0-00001 BLUE
0800-0111B0
PLAIN BEARING 2 REPL BY 0800-011103-00021 BLUE@THICK
0800-011103-0002
PLAIN BEARING 2 REPL BY 0800-011103-00011 RED@THIN
0800-011103-0001
PLAIN BEARING 1 REPL BY 0800-011102-00021 BLUE@THICK
0800-011102-0002
PLAIN BEARING 1 REPL BY 0800-011102-00011 RED@THIN
0800-011102-0001
OIL STRAINER
Position: 29
0800-011009
OIL SEAL 15X26X6 - REPL BY 0800-011203-10000 15x26x6
Position: 47
0800-011203
OIL FILTER ELEMENT
Position: 01
0800-011300-0004
O-RING 18x3.55
Position: 10
0110-013030
NOZZLE VALVE ASSY
Position: 21
0800-011400
MAGNETIC DRAIN BOLT M12x1.5
Position: 53
0180-011500
LH CRANKCASE RED (SMALL)
Position: 41
0800-011101-20030
LH CRANKCASE GROUP B/FOR BLUE BEARING SLEEVE/RUSSIA ONLY
Position: 40
0800-011101-20040
LH CRANKCASE ASSY GROUP B/FOR BLUE BEARING SLEEVE, ONLY FOR RUSSIA
Position: 38
0800-011100-20040
LH CRANKCASE ASSY GROUP A/FOR RED BEARING SLEEVE, ONLY FOR RUSSIA
Position: 37
0800-011100-20030
LH CRANKCASE ASSY - REPL BY 0800-0100A0-00020 GROUP B/FOR BLUE BEARING SLEEVE
Position: 33
0800-011100-20020
LH CRANKCASE ASSY - REPL BY 0800-0100A0-00010 GROUP A/FOR RED BEARING SLEEVE
Position: 32
0800-011100-20010
LH CRANKCASE A (RED). SMALL
Position: 39
0800-011101-20010
JOINT, BREATHER HOSE
Position: 22
0010-013006-0010
JOINT BOLT ASSY
Position: 09
0800-011500
IDLE GEAR, BREATHER
Position: 43
0800-011004
IDLE GEAR SHAFT, BREATHER
Position: 45
0800-011104
GEAR, BREATHER
Position: 48
0800-011201
GASKET, LH CRANKCASE COVER
Position: 38
0800-011002
GASKET, CRANKCASE REPL BY 0800-011001-10000
Position: 27
0800-011001
GASKET 14
Position: 44
0180-011006
DOWEL PIN Dia 8x14
Position: 09
0010-080008
DOWEL PIN Dia 10x14
Position: 03
0010-021005
DIPSTICK, ENGINE OIL
Position: 17
0110-013001
CLAMP A14
Position: 17
30601-114010
CIRCLIPS FOR SHAFT10 10
Position: 41
30801-01005
CHAIN GUARD
Position: 44
0800-011007
BREATHER HOSE
Position: 18
0010-013007
BREATHER ASSY
Position: 51
0800-011200
BOLT, LEAD HOLDER REPL BY 0180-014004-00100
Position: 12
0180-014004-0020
BOLT M8X60 REPL BY 0130-011109-0010 M8x60
Position: 44
0130-011109-0030
BOLT M8X50 REPL BY 0040-012006-0010 M8X50
Position: 06
0040-012006-0030
BOLT M8x12.5, FLANGE M8x12.5
Position: 32
0180-332002-0020
BOLT M6X55 REPL BY 0010-021018-0010 M6x55
Position: 25
0010-021018-0030
BOLT M6X16 REPL BY 0010-090005-0010 M6x16
Position: 13
0010-090005-0030
BOLT M14X1.5X32 REPL BY 0180-011007-0010 M14x1.5
Position: 23
0180-011007-0030
BEARING 17
Position: 16
30400-01704
BEARING 10
Position: 49
30400-01003
